Place of Origin:
Hunan, China
Brand Name:
TAKUMI
Model Number:
LD7RAIP
Certifiion:
ISO14001/TS16949, ISO/TS 16949 ISO9001
Contact Us
Electrode Material: Iridium
Thread Size: 0.472"
Thread Reach: 26.5 mm
Ground Electrode Quantity: 1
Gap: 0.044"
Spark Plug Seat Style: Flat
Heat Range: 7
Longevity: 80-100k Miles
Thread Diameter: 12 mm
Overall Height: ISO
Resistance: 5 kOhm
Insulator Height: 50 mm
Center Electrode Core Material: Copper Core
Ground Configuration: Standard
Ground Electrode Core Material: Nickel Core
Ground Electrode Tip Design: Standard
Insulator Type: Projected
Nominal Gap: 0.044"
Designed for faster starts and quicker acceleration
Better fuel economy and lower emissions
OE approved design
Laser welded iridium center electrode tip
Platinum disc welded to backside of ground electrode
Ideal for appliions with DIS (Distributorless Ignition System) Òwaste sparkÓ ignition systems that require double precious metal spark plugs
Manufactured using triple-gasket sealing process to prevent leakage through the shell
Alumina silie insulator for strength and optimal heat transfer
Cold-rolled threads for easier removal and installation
Corrugated ribs eliminate misfire causing ÒflashoverÓ
Trivalent metal plating
Last 80 to 100 thousand miles
| Model | LD7RAIP |
| Thread size | M12x1.25 |
| Reach | 26.5 mm |
| Hex | 14mm |
| Seat Type | Flat |
| Gap | 0.9-1.0mm |
| Heat Range | 7 |
| Electrode type | J type |
| Resistor | Yes |
| Center electrode material | copper |
