Place of Origin:
CHINA
Brand Name:
TAKUMI
Model Number:
R5B12-77C
Certifiion:
TS16949 / ISO9001
Contact Us
1.Detail Specifiion
| Type | R5B12-77C |
| Thread | M18x1.5 |
| Reach | 20.6mm |
| Hex | 22.2mm |
| Seat Type | Flat |
| Gap | 0.3mm |
| Heat Range | 77 |
| Electrode Type | Double "J" Gap Iridium electrode |
| Resistor or Non-Resistor | Resistor |
| Electrode Enhancements | Iridium |
| Replacement |
Denso: GI3-5/GI3-1/GI3-3 erpillar: 243-4291 Waukesha: 4924504 Cummins: 2866879/4924504 |
| Appliion |
Cummins: A19G,QSV Guascor:FG180,FGLD180,FG240,FCLD240,FGLD360,FGLD480. Jenbacher:208 612 12-Cyl.After 9/95,J616 16-Cyl. After 9/95 Perkins:4000 Series Superior 1706G2,1712G1. Wartsila Model:W25SG,W28SG,W34SG. Waukesha:9390GL(13/16Rch Hds),5115GL,5108GL(13/16Rch Hds),5790GL(13/16Rch Hds),7042GL(13/16 Rch Hds),2895GL(13/16 Rch Hds),3521GL(13/16 Rch Hds),12V-AT25GL/AT27GL(13/16 Rch Hds),8L- AT25GL/AT27GL(13/16 Rch Hds), P48GL/GLD,L36GL/GLD,H24G,H24GL/GLD,F18G,F18GL/GLD. |
2. TAKUMI Advantages
-Advanced laser welding technology
-High dielectric ceramics
-Highly reliable monolithic resistors
-Special nickel plating with better corrosion resistance
TAKUMI Group Spark Plug Factory is the No.1 OE spark plug manufacturer in China, and covers approximately 60% of Chinese OE market.
We have the most reliable welding technologies of platinum and iridium;
Therefore, we can produce high quality spark plugs competing with any other supplier.
Now, we are asked to manufacture spark plugs as OE replacement for some famous brands.
3. Packing Information
>4 pcs in a tin.
>1 piece in plastic box.
>Pack as required.
