High Performance Industrial Spark Plug with M18x1.5 Thread 0.3mm Gap and Resistor for Gas Engines
Basic Properties
Place of Origin:
Hunan,China
Brand Name:
TAKUMI
Model Number:
R5B12-77
Trading Properties
Minimum Order Quantity:
1
Price:
By discussed
Standard Packaging:
Tin, Plastic box, white box, Carton,As cunstomer request
Delivery Time:
30 working days
Payment Terms:
L/C,D/A,D/P,T/T,Western Union
Supply Ability:
10000 pieces per month
Product Summary
High Performance Industrial Spark Plug Compatible with RB77WPCC, KB77WPCC, FB77WPCC, DENSO GI3-1, GI3-3, GI3-5, ALTRONIC L1863IP, BG RB777-1, and BERU 18GZ6-77-2 Technical Specifications Type R5B12-77 Thread M18x1.5 Hex 22.2 mm Seat Type Flat Gap 0.3 mm Heat Range 77 Resistor or Non-Resistor ...
Product Details
Highlight:
industrial spark plug RB77WPCC
,generator spark plug DENSO GI3-1
,high performance spark plug ALTRONIC L1863IP
Thread:
M18x1.5
Reach:
20.6mm (13/16”)
Hex:
7/8”(22.2mm)
Gap:
0.3mm
Heat Range:
77
Electrode:
"J" Gap Industrial Electrode
Resistor:
Yes
Model:
R5B12-77
Fit To:
Denso: GI3-1, GI3-5 Champion: FB77WPCC:243-4291
Product Description
High Performance Industrial Spark Plug
Compatible with RB77WPCC, KB77WPCC, FB77WPCC, DENSO GI3-1, GI3-3, GI3-5, ALTRONIC L1863IP, BG RB777-1, and BERU 18GZ6-77-2
Technical Specifications
| Type | R5B12-77 |
|---|---|
| Thread | M18x1.5 |
| Hex | 22.2 mm |
| Seat Type | Flat |
| Gap | 0.3 mm |
| Heat Range | 77 |
| Resistor or Non-Resistor | Resistor |
| Electrode Type | J |
Cross-References
| BO-SCH | 7306 (MR3DPP330), 7301 |
|---|---|
| CHAMPION | RB77WPCC / KB77WPCC |
| WAUKESHA | 60999Z/69919D |
| CU-MMINS | 4090121/4098162/4010981/4302738 |
| GUASCOR | 76.64.291/76.64.293/76.64.292, 289383 |
| CAT | 301-6663 / 194-8518 (alte Nummer) / 243-4291 |
| DENSO | GI3-3 / GI3-5 |
| SCANIA | Compatible models |
| PERKINS | Compatible models |
| FG WILSON | Compatible models |
• Equal lifespan compared to original equipment parts
• Competitively priced lower than original manufacturers
Product Features
- Fuel flexibility: Designed to handle different gas fuels
- Capable of working with variable loads
- Robust design for operation under severe conditions
- High operational availability
- Easy maintenance
Compatible Engine Applications
| Engine Make | Model |
|---|---|
| Cat | NATURAL GAS: G3500 Series, G3600 Series |
| Cu-mmins | Engines w/Special Adapter: Q19G |
| Guascor | FG180, FGLD180, FG240, FGLD240, FGLD360, FGLD480 |
| Jenbacher | J612 12-Cyl. After 9/95 |
| Perkins | 4000 Series |
| Superior | 1706G2, 1712G1 |
| Wartsila | Model W25SG, W28SG, W34SG |
| Waukesha | VHP SERIES V-16: 9390GL (13/16" Rch Hds), 5115GL, V-12: 5108GL (13/16" Rch Hds), 5790GL (13/16" Rch Hds), 7042GL (13/16" Rch Hds), 2895GL (13/16" Rch Hds), 3521GL (13/16" Rch Hds), AT SERIES V-12: 12V-AT25GL/AT27GL (13/16" Rch Hds), Inline-8: 8L-AT25GL/AT27GL (13/16" Rch Hds), VGF SERIES V-16: P48GL/GLD, V-12: L36GL/GLD, Inline-8: H24G, H24GL/GLD, Inline-6: F18G, F18GL/GLD |
Industrial Applications
- CHP Gas Engine
- Cogeneration Plants
- Power Plants
- Power House
- Cogeneration Generator
Product Images
Reference Applications
| Location | Fuel | Engine Type | Electrical Output | Thermal Output | Commissioning | Application Details |
|---|---|---|---|---|---|---|
| ARGILORE (Hondarribia, Spain) | Natural gas | 3 x FGLD 360 | 1.6 MW | 2.6 MW | 2009 / 2010 | Installation of a cogeneration plant for greenhouse and plant nursery. CO₂ Output ~600kg/h |
| WWTP ARROYO CULEBRO (Madrid, Spain) | Sewage gas | 2 x FGLD 480 3 x SFGLD 560 |
4.5 MW | 2005 / 2007 | Water treatment plant | |
| AFRICAN GLASS (Lagos, Nigeria) | Natural gas | 2 x SFGLD 560 1x SFGLD 360 |
1890 KW 610 KW |
2010 | Glass manufacturing & recycling industry. Exhaust energy for Glass processing. Hot water for heating. |
