M18x1.5 Thread 0.3mm Gap Resistor Type Spark Plug for Industrial Generators and Champion RB77WPCC Replacement
Basic Properties
Place of Origin:
Hunan,China
Brand Name:
TAKUMI
Model Number:
R5B12-77
Trading Properties
Minimum Order Quantity:
1
Price:
By discussed
Standard Packaging:
Tin, Plastic box, white box, Carton,As cunstomer request
Delivery Time:
30 working days
Payment Terms:
L/C,D/A,D/P,T/T,Western Union
Supply Ability:
10000 pieces per month
Product Summary
Replacement of Champion RB77WPCC Spark Plug Platinum Product Overview High-performance platinum spark plug designed as a direct replacement for Champion RB77WPCC, KB77WPCC, FB77WPCC, and equivalent models from BERU, DENSO, and ALTRONIC. Technical Specifications Type R5B12-77 Thread M18x1.5 Hex 22.2 ...
Product Details
Highlight:
Champion RB77WPCC spark plug replacement
,14mm generator spark plug
,platinum spark plug with warranty
Thread:
M18x1.5
Reach:
20.6mm (13/16”)
Hex:
7/8”(22.2mm)
Gap:
0.3mm
Heat Range:
77
Electrode:
"J" Gap Industrial Electrode
Resistor:
Yes
Model:
R5B12-77
Fit To:
Denso: GI3-1, GI3-5 Champion: FB77WPCC:243-4291
Product Description
Replacement of Champion RB77WPCC Spark Plug Platinum
Product Overview
High-performance platinum spark plug designed as a direct replacement for Champion RB77WPCC, KB77WPCC, FB77WPCC, and equivalent models from BERU, DENSO, and ALTRONIC.
Technical Specifications
| Type | R5B12-77 |
| Thread | M18x1.5 |
| Hex | 22.2 mm |
| Seat Type | Flat |
| Gap | 0.3 mm |
| Heat Range | 77 |
| Resistor or Non-Resistor | Resistor |
| Electrode Type | J |
Cross-References
| BO-SCH | 7306 (MR3DPP330), 7301 |
| CHAMPION | RB77WPCC / KB77WPCC |
| WAUKESHA | 60999Z / 69919D |
| CU-MMINS | 4090121 / 4098162 / 4010981 / 4302738 |
| GUASCOR | 76.64.291 / 76.64.293 / 76.64.292 / 289383 |
Key Benefits
- Equal lifespan compared to original equipment
- Competitively priced alternative to OEM parts
Product Features
- Fuel flexibility: Compatible with different gas fuels
- Capable of working with variable loads
- Robust design for operation under severe conditions
- High operational availability
- Easy maintenance and installation
Additional Cross-References
- Beru 18GZ6-77
- Beru Z162
- Champion stk 634
- CU-MMINS 4010981
- Denso 6116
- Denso GI3-1
- Denso GI3-1A
- Denso GI3-3
- Denso GI3-3A
- Denso GI3-5A
- PERKINS 486-37
- WAUKESHA 60999Z
- WAUKESHA 69919
- WAUKESHA 69919A
- WAUKESHA 69919C
- WAUKESHA 69919D
Compatible Applications
- CU-MMINS: Q19G, QSV81-V16, QSV91-V18
- GUASCOR: FG180, FGLD180, FG240, FGLD240, FGLD360, FGLD480
- J612, J616, J620 (1995/9 - BMEP = 16 bar or less)
- 4000 Series
- SUPERIOR: 1706G2, 1712G1
- WARTSILA: W25SG, W28SG, W34SG, W20V, 34SG
- WAUKESHA AT Series: 8L-AT25GL / AT27GL (13/16" Reach Heads), 12V-AT25GL / AT27GL (13/16" Reach Heads)
- WAUKESHA VGF Series Inline 6: F18G, F18GL/GLD
- WAUKESHA VGF Series Inline 8: H24G, H24GL/GLD
- WAUKESHA VGF Series V-12: L36GL/GLD
- WAUKESHA VGF Series V-16: P48GL/GLD
- WAUKESHA VHP Series Inline 6: 2895GL (13/16" Reach Heads), 3521GL (13/16" Reach Heads)
- WAUKESHA VHP Series V-12: L5108GL (13/16" Reach Heads), L5790GL (13/16" Reach Heads), L7042GL (13/16" Reach Heads)
- WAUKESHA VHP Series V-16: P5115GL, P9390GL (13/16" Reach Heads)
- CHP Gas Engine
- Cogeneration Plants
- Power Plants
- Power House
- Cogeneration generator
Product Images
Reference Applications
ARGILORE (Hondarribia, Spain)
| Fuel | Natural gas |
| Engine Type | 3 x FGLD 360 |
| Electrical Output | 1.6 MW |
| Thermal Output | 2.6 MW |
| Commissioning | 2009 / 2010 |
Installation of a cogeneration plant for greenhouse and plant nursery. CO₂ Output ~600kg/h
WWTP ARROYO CULEBRO (Madrid, Spain)
| Fuel | Sewage gas |
| Engine Type | 2 x FGLD 480 | 3 x SFGLD 560 |
| Electrical Output | 4.5 MW |
| Thermal Output | Not specified |
| Commissioning | 2005 / 2007 |
Water treatment plant installation
AFRICAN GLASS (Lagos, Nigeria)
| Fuel | Natural gas |
| Engine Type | 2 x SFGLD 560 | 1x SFGLD 360 |
| Electrical Output | 1890 KW | 610 KW |
| Thermal Output | Not specified |
| Commissioning | 2010 |
Glass manufacturing & recycling industry. Exhaust energy for Glass processing. Hot water for heating.
