1245-2074 Generator S- R6A12 Industrial Spark Plug

Minimum Order Quantity : 1pcs Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
Place of Origin: China Brand Name: TAKUMI
Certification: ISO9001 TS 16949 Model Number: S-R6A12

Detail Information

Thread Length: M18*1.5 Hex Size: 22.6mm
GAP: 0.3MM Seat Type: FLAT
Replace: 1245-2074 Resistor Or Not: Resistor
Cable Length: 540 Reference Codes: S-R6A12
Gas Type: Natural Gas,coal Miner Gas,landfill Gas,biogas S-R6A12 Engine: 1245-2074
S-R6A12 Engine Number: 1245-2074 S-R6A12 Match With: 1245-2074
High Light:

S- R6A12 Industrial Spark Plug

,

1245-2074 Industrial Spark Plug

,

1245-2074 Generator Spark Plug

Product Description

1245-2074 generator high performance S- R6A12 Industrial Spark Plug



Application:1245-2074​ generator spark plug S-R6A12 match for 1245-2074​  1230-164  FOR MWM TCG 2020

TAKUMI R6GC1-77 industrial spark plug



TAKUMI Type S-R6A12
Thread M18x1.5
Reach 26mm
Hex 22.2mm
Seat Type FLAT
Gap 0.3mm
CABLE LENGTH  540MM
Electrode Type Prechamber  "Gap"
Resistor or Non-Resistor Resistor
Notes Replace
1245-2074 updated from old version 1230-1641 for MWM TCG 2020



1245-2074 Generator S- R6A12 Industrial Spark Plug 01245-2074 Generator S- R6A12 Industrial Spark Plug 1







Operation:

  • The plug is connected to the high voltage generated by an ignition coil or magneto. As the electrons flow from the coil, a voltage difference develops between the central electrode and side electrode. No current can flow because the fuel and air in the gap is an insulator, but as the voltage rises further, it begins to change the structure of the gases between the electrodes. Once the voltage exceeds the dielectric strength of the gases, the gases become ionized. The ionized gas becomes a conductor and allows electrons to flow across the gap. Spark plugs usually require voltage of 12,000–25,000 volts or more to 'fire' properly, although it can go up to 45,000 volts. They supply higher current during the discharge process resulting in a hotter and longer-duration spark.
  • As the current of electrons surges across the gap, it raises the temperature of the spark channel to 60,000 K. The intense heat in the spark channel causes the ionized gas to expand very quickly, like a small explosion. This is the 'click' heard when observing a spark, similar to lightning and thunder.
  • The heat and pressure force the gases to react with each other, and at the end of the spark event there should be a small ball of fire in the spark gap as the gases burn on their own. The size of this fireball or kernel depends on the exact composition of the mixture between the electrodes and the level of combustion chamber turbulence at the time of the spark. A small kernel will make the engine run as though the ignition timing was retarded, and a large one as though the timing was advanced.


We are the No.1 spark plug manufacturer in China since 1961, with ISO 9000,TS 16949 Quality System Certification. The high quality of our products is the same as famous brands all over the world, while our price is more competitive. Welcome to visit our factory.





1245-2074 Generator S- R6A12 Industrial Spark Plug 2

1245-2074 Generator S- R6A12 Industrial Spark Plug 3

1245-2074 Generator S- R6A12 Industrial Spark Plug 4

1245-2074 Generator S- R6A12 Industrial Spark Plug 5

1245-2074 Generator S- R6A12 Industrial Spark Plug 6



Summary

Spark plug Description
Type R6GC1-77
Suitable for Replace
cat 199-9012 284-8313
Main Market Europe, America, Africa ,Australian ,Southeast Asia and the Middle East.
Technical 1 Advanced Laser Welding Technology
2 High Dielectric Ceramics
3 Highly reliable monolithic resistor
4 Special Nickel plating with better corrosive resistance
Packaging 1. 4 pcs spark plugs in a tin
2.1 piece in plastic box
3. Pack as required
Quality ISO/TS 16949 /ISO 9001 QUALITY SYSTEM CERTIFIED
Production Capacity More than 1000 pcs each month
MOQ 48 pcs each shipment
Payment term T/T , L/C or can be negotiated
Place of original Hunan , china
Lead time About 40 days after received the deposit
Sample policy Free samples for serious buyers, but the cost of delivery is collect.
Port

Any port of China







Why choose us?



1. Over 60 years experiences in auto parts

2. Products under ISO9001, TS 16949 quality system certification

3. Good raw material and advanced technology to ensure high quality

4. Diversified products with reliable performance and competitive factory price

5. Strict on quality and 100% inspection

6. Professional technical support and service.

7. OEM accepted, tiral order accepted.



Shipping details:



1. We can ship your item by DHL,FEDEX,UPS,EMS(Express Mail Service),or other shipping ways as your request.

2. We take great care in packaging ensure that every item will shipment to you safe.
