Place of Origin:
CHINA
Brand Name:
TAKUMI
Model Number:
R5B12-77
Certifiion:
ISO/TS 16946 ISO9001
Contact Us
| Name | Premium Industrial Spark Plug |
| Car Fitments | For Industrial Engine 3500 |
| Material | Iridium/Platinum |
| OE number: RB77WPCC 69919d | |
| We can meet the customer's requirement to change the material to control the cost | |
| Type |
Spark Plugs OEM no:rb77wpcc Electrode Gap Setting: Refer to Operation Maintenance Manual for your engine or contact local dealer |
| Quantity | The quantity is unlimited. more quantity, better price. |
| Payment | T/T. 30% deposit in advance and 70% before shipping. |
| Packing detail | A.Neutral packing |
| B.Original packing | |
| C.Making the packing according to customer's requirement . | |
| Deliever time | Within 7-20 days depend on order quantity |
Features of Spark Plug:
1. Multi-ribbed insulator eliminate flashover.
2. 95% pure alumina provides super insulation,strong resistent to heat shock,great mechanic and electric features.
3. Nickel plated shell prevents oxidation and corrosion.
4. Electrical heat crimping process ensures absolute gas-tight fit.
5. Inner sealing with conductive glass ensures a fine conductivity and sealing.
6. Multi-layer gaskets are elasticly strong and realible in sealing.
7. Copper core electrode can prevent oxidation and corrosion,makes it has good electric and heat conductivity ,enables the spark plug has a long service life.
| TAKUMI | R5B12-77 |
| Thread | M18*1.5 |
| Reach | 20.6mm |
| Hex | 22.2mm |
| Seat Type | Gasket |
| Gap | 0.3mm |
| Heat Range | 77 |
| Electrode Type | double ''j'' gap iridium electrode |
| Resistor or Non-Resistor | Resistor |
| notes |
Jenbacher engines G3500 G3600 Series CUMMINS Q19G QSV GUASCOR FG180 FGLD 180 240 360 480 WARTSILA |
Equal life time to the original.
Competively lower price than the original
Torch Group Spark Plug Factory is the No.1 OE spark plug manufacturer in China,
and covers approximately 60% of Chinese OE market.
We have the most reliable welding technologies of platinum and iridium;
therefore, we can produce high quality spark plugs competing with any other supplier.
Now, we are asked to manufacture spark plugs as OE replacement for some famous brands.
TO GET BETTER FUEL ECONOMY
SAVE OUR PLANET !
1.torch spark plug use noble metal and have a open design.so the spark travels directly toward the air-fuel mixture which maximizes the burn. The result is a faster flame kernel, a more complete combustion, greater power and higher fuel efficiency.
2.Unburned fuel is bad for our planet and wasteful of your hard-earned dollars. Help to make a difference. Replace your standard plug with torch spark plug for a cleaner, more complete burn.
3.Torch is an ideal opportunity for you to help reduce the amount of carbon monoxide, carbon dioxide and other harmful hydrocarbons that are exhausted into the air we
breathe. Let's join together to creat a better world!
Appliion |
|
Gas engines form a major part of our in-house expertise at Stark. With 15 years of experience in design, operation and maintenance of biogas-fueled cogeneration plants, we know a thing or two about what makes an engine happy and what seems to always cost more money than hoped for.
Spark plug cost- One of the things that really has the potential to put a dent in your maintenance budget is spark plugs. A single spark plug from brands like Jenbacher or MWM will quickly set you back anywhere between $800 and $1200 (AUD). In perfect circumstances, these may last anywhere from 6,000 up to 10,000 runhours. So that puts us at a minimum cost of plugs of about $10,000 per year for a 12-cylinder engine.
When the fuel is biogas (sewage or land fill), the plugs however don't last anywhere near that long. It depends very much on the type of contaminants in the gas and the type of spark plugs, but it can be expected for untreated gas that the plug lifetime will drop to half or less, effectively doubling the cost.
Biogas cleaning- The engine vendor's out there will happily advise you to clean the gas to the point where all the nasties are taken out: moisture, hydrogen sulphide (H2S), siloxanes, particulates... they have a nice and tight technical specifiion for all of it. While there are many good arguments for gas conditioning, sometimes it feels a bit of a free pass for the engine vendors. Gas cleaning is not a particularly cheap exercise. And what to do when your capital project is done and dusted and all of a sudden your gas composition starts to change - not uncommon in a biological process... it's biological after all.
Package and Delivery
FAQ
Q1. What is your terms of packing?
A: Generally, we pack our goods in neutral white boxes and brown cartons. If you have legally registered patent,
we can pack the goods in your branded boxes after getting your authorization letters.
Q2. What is your terms of payment?
A: T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages
before you pay the balance.
Q3. What is your terms of delivery?
A: EXW, FOB, CFR, CIF, DDU.
Q4. How about your delivery time?
A: Generally, it will take 30 to 60 days after receiving your advance payment. The specific delivery time depends
on the items and the quantity of your order.
Q5. Can you produce according to the samples?
A: Yes, we can produce by your samples or technical drawings. We can build the molds and fixtures.
Q6. What is your sample policy?
A: We can supply the sample if we have ready parts in stock, but the customers have to pay the sample cost and
the courier cost.
Q7. Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery
Q8: How do you make our business long-term and good relationship?
A:1. We keep good quality and competitive price to ensure our customers benefit ;
2. We respect every customer as our friend and we sincerely do business and make friends with them,
no matter where they come from.
